| Part Number | LQ14D412 |
| Mark | SHARP |
| Gréisst | 13.8 |
| Applikatioun | DMPC |
| Opléisung | 640×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 180 |
| CR | 100:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | TTL |
| Panel Mark | SHARP |
| Panel Modell | LQ14D412 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 13.8 inch |
| Resolutioun | 640(RGB)×480 , VGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 281.3×207.8 mm |
| skizzéieren | 330×242 mm |
| Uewerfläch | Antiglare (Haze 6%), Hard coating (2H) |
| Hellegkeet | 180 cd/m² (Typ.) |
| Kontrast Verhältnis | 100:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 30/50 (Typ.)(Tr/Td) |
| Vue Wénkel | 45/45/10/30 (Min.)(CR≥10)(L/R/U/D) |
| Lampe Typ | 2 pcsCCFLEmbedded (Inverter) |
| Signal Interface | Parallel RGB (1 ch, 8-bit), 40 pins |
| Input Volt | 5.0V (Typ.)(VCC) |
| Applikatioun | DMPC |
