| Part Number | LTM170EU-A01 |
| Mark | Samsung |
| Gréisst | 17.0 |
| Applikatioun | DMPC |
| Opléisung | 1280×1024 |
| Zesummesetzung | LCM |
| Hellegkeet | 270 |
| CR | 400:1 |
| Faarwen | 16.2M |
| Géigeliicht | CCFL |
| Interface | Analog |
| Panel Mark | SAMSUNG |
| Panel Modell | LTM170EU-A01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 17.0 inch |
| Resolutioun | 1280(RGB)×1024 , SXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 337.92×270.336 mm |
| skizzéieren | 358.5×296.5×25.4 mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 270 cd/m² (Typ.) |
| Kontrast Verhältnis | 400:1 (Typ.) |
| weisen Faarwen | 16.2M (6-bit + FRC), CIE193165% |
| Äntwert Zäit | 5/20 (Typ.)(Tr/Td) |
| Vue Wénkel | 60/60/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 4 pcsCCFLEmbedded (Inverter) |
| Signal Interface | Analog RGB, 27 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | DMPC |
