| Part Number | TX43D14VC0CAB |
| Mark | KOE |
| Gréisst | 17.0 |
| Applikatioun | DMPC |
| Opléisung | 1280×1024 |
| Zesummesetzung | LCM |
| Hellegkeet | 230 |
| CR | 400:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | HITACHI |
| Panel Modell | TX43D14VC0CAB |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 17.0 inch |
| Resolutioun | 1280(RGB)×1024 , SXGA |
| Display Modus | IPS-Pro, Normally Black, Transmissive |
| aktiv Beräich | 337.92×270.336 mm |
| skizzéieren | 368×306 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 230 cd/m² (Typ.) |
| Kontrast Verhältnis | 400:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC) |
| Äntwert Zäit | 20/20 (Typ.)(Tr/Td) |
| Vue Wénkel | |
| Frequenz | 60Hz |
| Lampe Typ | 4 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | DMPC |
| AA170EC01 | Mitsubishi | 17.0 | 1280×1024 |
| B170PW03 V1 | AUO | 17.0 | 1440×900 |
| B170UW02 V0 | AUO | 17.0 | 1920×1200 |
| G170ETN01.0 | AUO | 17.0 | 1280×1024 |
| LM170E03-TLH1 | LG Display | 17.0 | 1280×1024 |
| LTA170D200F | TOSHIBA | 17.0 | 1280×1024 |
| LTM170EI-A01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L31 | Samsung | 17.0 | 1280×1024 |
| M170ETN01.0 | AUO | 17.0 | 1280×1024 |
| TX43D14VC0CAB | KOE | 17.0 | 1280×1024 |
| LM170E01-TLBF | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLJ2 | LG Display | 17.0 | 1280×1024 |
| LM171WX3-TLC1 | LG Display | 17.1 | 1440×900 |
| LM185WH1-TLF1 | LG Display | 18.5 | 1366×768 |
| LM200WD1-TLC1 | LG Display | 20.0 | 1600×900 |
| LM201U04-A3KC | LG Display | 20.1 | 1600×1200 |
| LM201W01-B6K1 | LG Display | 20.1 | 1680×1050 |
| LM270WQ1-SDE3 | LG Display | 27.0 | 2560×1440 |
| M240HW02 V1 | AUO | 24.0 | 1920×1080 |
| NL128102BC23-03 | NLT | 15.4 | 1280×1024 |
