| Part Number | LTL101DL03-T01 |
| Mark | Samsung |
| Gréisst | 10.1 |
| Applikatioun | PAD |
| Opléisung | 2560×1600 |
| Zesummesetzung | LCM |
| Hellegkeet | 370 |
| CR | 800:1 |
| Faarwen | 16.2M |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | SAMSUNG |
| Panel Modell | LTL101DL03-T01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 10.1 inch |
| Resolutioun | 2560RG(BW)×1600 , WQXGA |
| Display Modus | PLS, Normally Black, Transmissive |
| aktiv Beräich | 216.576×135.36 mm |
| skizzéieren | 232.22×156.92×5.2 mm |
| Uewerfläch | Glare (Haze 0%), Hard coating (2H) |
| Hellegkeet | 370 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 16.2M (6-bit + FRC) |
| Äntwert Zäit | 16 (Typ.)(Tr+Td) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 7S6PWLEDEmbedded (LED Driver) |
| Signal Interface | eDP (4 Lanes), 45 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | PAD |
