| Part Number | VVX10F011B00 |
| Mark | Panasonic |
| Gréisst | 10.1 |
| Applikatioun | PAD |
| Opléisung | 1920×1200 |
| Zesummesetzung | LCM |
| Hellegkeet | 650 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | Panasonic |
| Panel Modell | VVX10F011B00 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 10.1 inch |
| Resolutioun | 1920(RGB)×1200 , WUXGA |
| Display Modus | IPS, Normally Black, Transmissive |
| aktiv Beräich | 217.44×135.9 mm |
| skizzéieren | 228.86×152.5×4.18 mm |
| Uewerfläch | Hard coating, Antireflection |
| Hellegkeet | 650 cd/m² (Min.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193150% |
| Äntwert Zäit | 35 (Max.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 10S6PWLEDEmbedded (LED Driver) |
| Signal Interface | eDP (2 Lanes), 30 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | PAD |
