| Part Number | VVX10F002A00 |
| Mark | Panasonic |
| Gréisst | 10.1 |
| Applikatioun | PAD |
| Opléisung | 1920×1200 |
| Zesummesetzung | LCM |
| Hellegkeet | 450 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Panel Mark | Panasonic |
| Panel Modell | VVX10F002A00 1 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 10.1 inch |
| Resolutioun | 1920(RGB)×1200 , WUXGA |
| Display Modus | IPS, Normally Black, Transmissive |
| aktiv Beräich | 217.44×135.9 mm |
| skizzéieren | 227.1×147.1×4.13 mm |
| Uewerfläch | Hard coating, Antireflection |
| Hellegkeet | 450 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193150% |
| Äntwert Zäit | 30 (Max.)(Tr/Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 6S6PWLEDEmbedded (LED Driver) |
| Signal Interface | MIPI (4 data lanes), 40 pins |
| Input Volt | 3.7V (Typ.) |
| Applikatioun | PAD |
| B101EAN01.5 | AUO | 10.1 | 1280×800 |
| B101EVN06.1 | AUO | 10.1 | 1280×800 |
| G101STN01.0 | AUO | 10.1 | 1024×600 |
| HSD101PWW1-G10 | HannStar | 10.1 | 1280×800 |
| N101L6-L0B | Innolux | 10.1 | 1024×600 |
| VVX10F002A00 | Panasonic | 10.1 | 1920×1200 |
| VVX10F004B00 | Panasonic | 10.1 | 1920×1200 |
| VVX10F008B00 | Panasonic | 10.1 | 1920×1200 |
| VVX10F011B00 | Panasonic | 10.1 | 1920×1200 |
| VVX10F034N00 | Panasonic | 10.1 | 1920×1200 |
| BP070WS1-200 | BOE | 7.0 | 1024×600 |
| BP101WX1-100 | BOE | 10.1 | 1280×800 |
| HV070WX2-1E0 | HYDIS | 7.0 | 800×1280 |
| HX104X01-212 | HYDIS | 10.4 | 1024×768 |
| LP097QX1-SPAV | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPC2 | LG Display | 9.7 | 2048×1536 |
| LP125WH2-SPR1 | LG Display | 12.5 | 1366×768 |
| LTL106HL02-001 | Samsung | 10.6 | 1920×1080 |
| P070ACB-DB1 | Innolux | 7.0 | 600×1024 |
| Q070LRE-LB1 | Innolux | 7.0 | 1024×600 |
