| Part Number | LTL106HL02-001 |
| Mark | Samsung |
| Gréisst | 10.6 |
| Applikatioun | PAD |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | SAMSUNG |
| Panel Modell | LTL106HL02-001 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 10.6 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | PLS, Normally Black, Transmissive |
| aktiv Beräich | 234.72×132.03 mm |
| skizzéieren | 244.92×145.06×4.56 mm |
| Uewerfläch | Glare (Haze 0%), Hard coating (2H) |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193150% |
| Äntwert Zäit | 16 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 6S6PWLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (2 ch, 8-bit), 60 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | PAD |
| CLAA080WQ05 | CPT | 8.0 | 800×1280 |
| CLAA101WJ01 | CPT | 10.1 | 1366×768 |
| HX104X01-210 | HYDIS | 10.4 | 1024×768 |
| LP097X02-SLQ1 | LG Display | 9.7 | 1024×768 |
| LP101WX2-SLP1 | LG Display | 10.1 | 1280×800 |
| LTL106HL02-001 | Samsung | 10.6 | 1920×1080 |
| LTL120QL01-001 | Samsung | 12.0 | 2160×1440 |
| N101BCG-L21 | Innolux | 10.1 | 1366×768 |
| TV080X0M-NS0 | BOE | 8.0 | 768×1024 |
| YX101GL-01A | SEBO | 10.1 | 1280×800 |
