AUO B101UAN01.7 HW0A Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


B101UAN01.7 HW0A

B101UAN01.7 HW0A
B101UAN01.7 HW0A
B101UAN01.7 HW0A
B101UAN01.7 HW0A thumb B101UAN01.7 HW0A thumb B101UAN01.7 HW0A thumb
Mark
AUO
Gréisst
10.1
Applikatioun
PAD
Opléisung
1920×1200
Zesummesetzung
LCM
Hellegkeet
400
CR
800:1
Faarwen
16.7M
Backlight
WLED
Interface
MIPI
In Stock
7648
Spezifikatioune

Part Number B101UAN01.7 HW0A
MarkAUO
Gréisst10.1
ApplikatiounPAD
Opléisung1920×1200
ZesummesetzungLCM
Hellegkeet400
CR800:1
Faarwen16.7M
GéigeliichtWLED
InterfaceMIPI
Panel MarkAUO
Panel ModellB101UAN01.7 HW0A
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst10.1 inch
Resolutioun1920(RGB)×1200 , WUXGA
Display ModusAHVA, Normally Black, Transmissive
aktiv Beräich216.81×135.5 mm
skizzéieren227.72×147.8×5.35 mm
UewerflächGlare (Haze 0%)
Hellegkeet400 cd/m² (Typ.)
Kontrast Verhältnis800:1 (Typ.)
weisen Faarwen16.7M (8-bit), CIE193150%
Äntwert Zäit25 (Typ.)(Tr+Td)
Vue Wénkel85/85/85/85 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe TypWLEDEmbedded (LED Driver)
Signal InterfaceMIPI (4 data lanes), 34 pins
Input Volt3.3V (Typ.)
ApplikatiounPAD
Famill Modell
B101UAN01.1 AUO 10.1 1920×1200
B101UAN01.7 HW0A AUO 10.1 1920×1200
B101UAN01.7 HW1A AUO 10.1 1920×1200
B101UAN01.7 HW2A AUO 10.1 1920×1200
B101UAN01.9 AUO 10.1 1920×1200
B101UAN01.C AUO 10.1 1920×1200
B101UAN01.E AUO 10.1 1920×1200
B101UAN02.1 AUO 10.1 1920×1200
B101UAN07.0 AUO 10.1 1200×1920
B101UAN07.2 AUO 10.1 1200×1920
