| Part Number | VVX07H005A00 |
| Mark | Panasonic |
| Gréisst | 7.0 |
| Applikatioun | PAD |
| Opléisung | 800×1280 |
| Zesummesetzung | LCM |
| Hellegkeet | 450 |
| CR | 1000:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | MIPI |
| Panel Mark | Panasonic |
| Panel Modell | VVX07H005A00 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.0 inch |
| Resolutioun | 800(RGB)×1280 , WXGA |
| Display Modus | IPS, Normally Black, Transmissive |
| aktiv Beräich | 94.2×150.72 mm |
| skizzéieren | 104.32×161.67×3.8 mm |
| Uewerfläch | Hard coating |
| Hellegkeet | 450 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 30 (Max.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥100)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 5S5PWLEDWithout Driver |
| Signal Interface | MIPI (4 data lanes), 34 pins |
| Input Volt | 1.8/3.3V (Typ.)(VCC/VDD) |
| Applikatioun | PAD |
