| Part Number | AT070TN94 |
| Mark | Innolux |
| Gréisst | 7.0 |
| Applikatioun | CNS |
| Opléisung | 800×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | 500:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | INNOLUX |
| Panel Modell | AT070TN94 1 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.0 inch |
| Resolutioun | 800(RGB)×480 , WVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 154.08×85.92 mm |
| skizzéieren | 164.9×100×6 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193150% |
| Äntwert Zäit | 10/15 (Typ.)(Tr/Td) |
| Vue Wénkel | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| Lampe Typ | 3S9PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6/8-bit), 50 pins |
| Input Volt | 3.3/10.4/16.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| Applikatioun | CNS |
| AT070TN01 | Innolux | 7.0 | 480×234 |
| AT070TN07 V.A | Innolux | 7.0 | 480×234 |
| AT070TN07 V.D | Innolux | 7.0 | 480×234 |
| AT070TN83 | Innolux | 7.0 | 800×480 |
| AT070TN90 | Innolux | 7.0 | 800×480 |
| AT070TN92 | Innolux | 7.0 | 800×480 |
| AT070TN92 V.1 | Innolux | 7.0 | 800×480 |
| AT070TN92 V.4 | Innolux | 7.0 | 800×480 |
| AT070TN93 | Innolux | 7.0 | 800×480 |
| AT070TNA2 V.1 | Innolux | 7.0 | 1024×600 |
| A070VW05 V0 | AUO | 7.0 | 800×480 |
| AM-480272-043D | Other | 4.3 | 480×272 |
| CLAA080LG02AW | CPT | 8.0 | 800×480 |
| DJ080PA-01C | Innolux | 8.0 | |
| LB070WQ4-TM06 | LG Display | 7.0 | 480×234 |
| LQ038Q5DR01 | SHARP | 3.8 | 320×240 |
| LQ042T5DZ01A | SHARP | 4.2 | 480×272 |
| LQ080Y5DG02 | SHARP | 8.0 | 800×480 |
| M050SWN1 R2 | IVO | 5.0 | 480×234 |
| YXD101301000-60 | SEBO | 10.1 | 1024×600 |
