| Part Number | AT070TN07 V.A |
| Mark | Innolux |
| Gréisst | 7.0 |
| Applikatioun | VDP |
| Opléisung | 480×234 |
| Zesummesetzung | LCM |
| Hellegkeet | 200 |
| CR | 300:1 |
| Faarwen | Full color |
| Géigeliicht | WLED |
| Interface | Analog |
| Panel Mark | INNOLUX |
| Panel Modell | AT070TN07 V.A |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.0 inch |
| Resolutioun | 480(RGB)×234 |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 154.08×86.58 mm |
| skizzéieren | 164.9×100 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 200 cd/m² (Typ.) |
| Kontrast Verhältnis | 300:1 (Typ.) |
| weisen Faarwen | Full color |
| Äntwert Zäit | 15/20 (Typ.)(Tr/Td) |
| Vue Wénkel | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| Lampe Typ | 2S9PWLEDWithout Driver |
| Signal Interface | TFT Specific Analog RGB, 26 pins |
| Input Volt | (3.3/5.0)/5.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
| Applikatioun | VDP |
