| Part Number | YXD101301000-60 |
| Mark | SEBO |
| Gréisst | 10.1 |
| Applikatioun | CNS |
| Opléisung | 1024×600 |
| Zesummesetzung | LCM |
| Hellegkeet | 1000 |
| CR | 600:1 |
| Faarwen | 16.2M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | SEBO |
| Panel Modell | YXD101301000-60 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 10.1 inch |
| Resolutioun | 1024(RGB)×600 , WSVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 222.72×125.28 mm |
| skizzéieren | 235×149.2×6.3 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 1000 cd/m² (Typ.) |
| Kontrast Verhältnis | 600:1 (Typ.) |
| weisen Faarwen | 16.2M (6-bit + FRC), CIE193152% |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 60 pins |
| Input Volt | 3.3/9.6/18/-6V (Typ.)(DVDD/AVDD/VGH/VGL) |
| Applikatioun | CNS |
