| Part Number | LT101MB02000 |
| Mark | JDI |
| Gréisst | 10.1 |
| Applikatioun | PAD |
| Opléisung | 1920×1200 |
| Zesummesetzung | LCM |
| Hellegkeet | 340 |
| CR | 500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Panel Mark | JDI |
| Panel Modell | LT101MB02000 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 10.1 inch |
| Resolutioun | 1920(RGB)×1200 , WUXGA |
| Display Modus | Normally Black, Transmissive |
| aktiv Beräich | 217.44×135.9 mm |
| skizzéieren | 228.1×147.5×3.89 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 340 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193160% |
| Äntwert Zäit | 60/40 (Max.)(Tr/Td) |
| Vue Wénkel | 70/70/70/70 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 5 stringsWLEDWithout Driver |
| Signal Interface | MIPI (4 data lanes), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | PAD |
| B101EAN01.1 | AUO | 10.1 | 1280×800 |
| CLAA101NC05 | CPT | 10.1 | 1024×600 |
| G101EVN01.3 | AUO | 10.1 | 1280×800 |
| HSD101PFW3-D00 | HannStar | 10.1 | 1024×600 |
| HSD101PHW1-A00 | HannStar | 10.1 | 1366×768 |
| HSD101PWW1-A00 Rev.4 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-B00 | HannStar | 10.1 | 1280×800 |
| LP101WS1-TLA1 | LG Display | 10.1 | 1024×576 |
| LP101WX1-SLP2 | LG Display | 10.1 | 1280×800 |
| LT101MB02000 | JDI | 10.1 | 1920×1200 |
| B080XAN02.0 | AUO | 7.9 | 768×1024 |
| B101EW05 V0 | AUO | 10.1 | 1280×800 |
| CLAA070WP03 | CPT | 7.0 | 800×1280 |
| EJ101IA-01C | Innolux | 10.1 | 1280×800 |
| HV121WX5-120 | HYDIS | 12.1 | 1280×800 |
| LP116WH4-SLN1 | LG Display | 11.6 | 1366×768 |
| LQ101K1LY02 | SHARP | 10.1 | 1280×800 |
| LTL101AL03-W01 | Samsung | 10.1 | 1280×800 |
| LTN070NL01-801 | Samsung | 7.0 | 1024×600 |
| N101ICG-L11 | Innolux | 10.1 | 1280×800 |
