| Part Number | LQ038Q5DR01 |
| Mark | SHARP |
| Gréisst | 3.8 |
| Applikatioun | CNS |
| Opléisung | 320×240 |
| Zesummesetzung | LCM |
| Hellegkeet | 450 |
| CR | 100:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | TTL |
| Panel Mark | SHARP |
| Panel Modell | LQ038Q5DR01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 3.8 inch |
| Resolutioun | 320(RGB)×240 , QVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 78.72×53.64 mm |
| skizzéieren | 117.6×69.45 mm |
| Uewerfläch | Antiglare, Antireflection |
| Hellegkeet | 450 cd/m² (Typ.) |
| Kontrast Verhältnis | 100:1 (Min.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 30/50 (Typ.)(Tr/Td) |
| Vue Wénkel | 65/65/40/65 (Typ.)(CR≥5)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 1 pcsCCFLWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| Input Volt | 3.3V (Typ.)(VCC) |
| Applikatioun | CNS |
| AT050TN35 | Innolux | 5.0 | 480×272 |
| CLAA080LG02AW | CPT | 8.0 | 800×480 |
| CLAA080NA01 CW | CPT | 8.0 | 1024×600 |
| CLAA102NA0DCW | CPT | 10.2 | 1024×600 |
| G121S1-L01 | Innolux | 12.1 | 800×600 |
| LA080WV1-TD01 | LG Display | 8.0 | 800×480 |
| LQ050A5BS01 | SHARP | 5.0 | 320×234 |
| TM062RDS01 | Tianma | 6.2 | 800×480 |
| TM062RDZG10 | Tianma | 6.2 | 800×480 |
| TX18D35VM0AAA | KOE | 7.0 | 800×480 |
