| Part Number | AT070TN01 |
| Mark | Innolux |
| Gréisst | 7.0 |
| Applikatioun | DPF |
| Opléisung | 480×234 |
| Zesummesetzung | LCM |
| Hellegkeet | 350 |
| CR | 300:1 |
| Faarwen | Full color |
| Géigeliicht | CCFL |
| Interface | Analog |
| Panel Mark | INNOLUX |
| Panel Modell | AT070TN01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.0 inch |
| Resolutioun | 480(RGB)×234 |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 154.08×86.58 mm |
| skizzéieren | 164.9×100×6 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 300:1 (Typ.) |
| weisen Faarwen | Full color |
| Äntwert Zäit | 15/20 (Typ.)(Tr/Td) |
| Vue Wénkel | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 1 pcsCCFLWithout Driver |
| Signal Interface | TFT Specific Analog RGB, 26 pins |
| Input Volt | 5.0/5.0/15.0/-10.0 (Typ.)(VCC/AVDD/VGH/VGL) |
| Applikatioun | DPF |
