| Part Number | ACX565AKM-7 |
| Mark | SONY |
| Gréisst | 3.5 |
| Applikatioun | MPH |
| Opléisung | 800×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 275 |
| CR | 500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | CDP |
| Panel Mark | SONY |
| Panel Modell | ACX565AKM-7 |
| Panel Typ | LTPS TFT-LCD , LCM |
| Panel Gréisst | 3.5 inch |
| Resolutioun | 800(RGB)×480 , WVGA |
| Display Modus | VSPEC II, Normally Black, Transflective |
| aktiv Beräich | 76.8×46.08 mm |
| skizzéieren | 87.9×52.18 mm |
| Uewerfläch | |
| Hellegkeet | 275 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.)(Transmissive)24:1 (Typ.)(Reflective) |
| weisen Faarwen | 16.7M (8-bit), CIE193170% |
| Äntwert Zäit | 12/7 (Typ.)(Tr/Td) |
| Vue Wénkel | |
| Frequenz | 60Hz |
| Lampe Typ | 3S2PWLEDWithout Driver |
| Signal Interface | CDP (2 Lane) + SPI, 24 pins |
| Input Volt | 1.8/2.75V (Typ.)(VDDI/VDD) |
| Applikatioun | MPH |
