| Part Number | PW050XS3 |
| Mark | E Ink |
| Gréisst | 5.0 |
| Applikatioun | CNS |
| Opléisung | 320×220 |
| Zesummesetzung | LCM |
| Hellegkeet | 350 |
| CR | 350:1 |
| Faarwen | Full color |
| Géigeliicht | CCFL |
| Interface | Analog |
| Panel Mark | PVI |
| Panel Modell | PW050XS3 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 5.0 inch |
| Resolutioun | 320(RGB)×220 |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 112.5×60.5 mm |
| skizzéieren | 125.4×74×6.5 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 350:1 (Typ.) |
| weisen Faarwen | Full color |
| Äntwert Zäit | 15/30 (Typ.)(Tr/Td) |
| Vue Wénkel | 60/60/50/35 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 1 pcsCCFLWithout Driver |
| Signal Interface | TFT Specific Analog RGB, 30 pins |
| Input Volt | 3.3/3.3/5.0/15.0/-12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VGL) |
| Applikatioun | CNS |
