| Part Number | LQ050T5DG01 |
| Mark | SHARP |
| Gréisst | 5.0 |
| Applikatioun | CNS |
| Opléisung | 400×240 |
| Zesummesetzung | LCM |
| Hellegkeet | 600 |
| CR | 800:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | SHARP |
| Panel Modell | LQ050T5DG01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 5.0 inch |
| Resolutioun | 400(RGB)×240 , WQVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 108×64.8 mm |
| skizzéieren | 120.6×75.2×16.8 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 600 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193150% |
| Äntwert Zäit | 35 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥5)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 4S2PWLEDWithout Driver |
| Signal Interface | CMOS (1 ch, 6-bit), 40 pins |
| Input Volt | 3.3/9.0V (Typ.)(VCC/VDC) |
| Applikatioun | CNS |
