| Part Number | LQ050T5DG02 |
| Mark | SHARP |
| Gréisst | 5.0 |
| Applikatioun | CNS |
| Opléisung | 400×240 |
| Zesummesetzung | LCM |
| Hellegkeet | 600 |
| CR | |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | SHARP |
| Panel Modell | LQ050T5DG02 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 5.0 inch |
| Resolutioun | 400(RGB)×240 , WQVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 108×64.8 mm |
| skizzéieren | 120.6×75.2 mm |
| Uewerfläch | |
| Hellegkeet | 600 cd/m² (Typ.) |
| Kontrast Verhältnis | |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | |
| Vue Wénkel | |
| Lampe Typ | WLED |
| Signal Interface | CMOS (1 ch, 6-bit) |
| rohs: | |
| Applikatioun | CNS |
