| Part Number | TM070WA-22L06 |
| Mark | SANYO |
| Gréisst | 7.0 |
| Applikatioun | CNS |
| Opléisung | 480×234 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | 100:1 |
| Faarwen | |
| Géigeliicht | CCFL |
| Interface | Analog |
| Panel Mark | TORISAN |
| Panel Modell | TM070WA-22L06 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.0 inch |
| Resolutioun | 480(RGB)×234 |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 154.08×87.05 mm |
| skizzéieren | 167×102 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 100:1 (Min.) |
| weisen Faarwen | |
| Äntwert Zäit | 30/20 (Typ.)(Tr/Td) |
| Vue Wénkel | 60/60/30/40 (Max.)(CR≥5)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 1 pcsCCFL |
| Signal Interface | TFT Specific Analog RGB, 24 pins |
| Input Volt | 5.3/15.0/-14V (Typ.)(VSH/VGH/VGL) |
| Applikatioun | CNS |
