| Part Number | H495TAN01.1 |
| Mark | AUO |
| Gréisst | 5.0 |
| Applikatioun | MPH |
| Opléisung | 720×1280 |
| Zesummesetzung | CELL |
| Hellegkeet | 0 |
| CR | 900:1 |
| Faarwen | 16.7M |
| Géigeliicht | No B/L |
| Interface | |
| Panel Mark | AUO |
| Panel Modell | H495TAN01.1 |
| Panel Typ | a-Si TFT-LCD , CELL |
| Panel Gréisst | 5.0 inch |
| Resolutioun | 720(RGB)×1280 , WXGA |
| Display Modus | AHVA, Normally Black, Transmissive |
| aktiv Beräich | 61.688×109.632 mm |
| skizzéieren | 63.67×115.85×0.3 mm |
| Uewerfläch | |
| Glas Déift | 0.15+0.15 mm |
| transmissivitéit | 3.26% (Typ.)(with Polarizer) |
| Kontrast Verhältnis | 900:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193194% |
| Äntwert Zäit | 35 (Max.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Chauffeur ic | COG Suggest HX8394-D21, N35521-DPAU, N35521S-DP8AU, OTM1284A-C6, OTM1287A-C8, R61318, RM68200 |
| Applikatioun | MPH |
