| Part Number | HSD015F4N2-B |
| Mark | HannStar |
| Gréisst | 1.5 |
| Applikatioun | MPH |
| Opléisung | 128×128 |
| Zesummesetzung | CELL |
| Hellegkeet | 0 |
| CR | 200:1 |
| Faarwen | 262K |
| Géigeliicht | No B/L |
| Interface | |
| Panel Mark | HannStar |
| Panel Modell | HSD015F4N2-B |
| Panel Typ | a-Si TFT-LCD , CELL |
| Panel Gréisst | 1.5 inch |
| Resolutioun | 128(RGB)×128 |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 26.112×28.16 mm |
| Uewerfläch | |
| Glas Déift | 0.50+0.50 mm |
| Kontrast Verhältnis | 200:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193163% |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 45/45/50/20 (Typ.)(CR≥10)(L/R/U/D) |
