Innolux M270HGE-L20 Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


M270HGE-L20

M270HGE-L20
M270HGE-L20
M270HGE-L20 thumb M270HGE-L20 thumb
Mark
Innolux
Gréisst
27.0
Applikatioun
DMPC
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
300
CR
1200:1
Faarwen
16.7M
Backlight
WLED
Interface
LVDS
In Stock
2350
Spezifikatioune

Part Number M270HGE-L20
MarkInnolux
Gréisst27.0
ApplikatiounDMPC
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet300
CR1200:1
Faarwen16.7M
GéigeliichtWLED
InterfaceLVDS
Panel MarkCHIMEI INNOLUX
Panel ModellM270HGE-L20
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst27.0 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusTN, Normally White, Transmissive
aktiv Beräich597.888×336.312 mm
skizzéieren630×368.2×14.6 mm
UewerflächAntiglare (Haze 25%), Hard coating (3H)
Hellegkeet300 cd/m² (Typ.)
Kontrast Verhältnis1200:1 (Typ.)
weisen Faarwen16.7M (8-bit)
Äntwert Zäit0.8/2.6 (Typ.)(Tr/Td)
Vue Wénkel85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ4 stringsWLEDWithout Driver
Signal InterfaceLVDS (2 ch, 8-bit), 30 pins
Input Volt5.0V (Typ.)
ApplikatiounDMPC
Famill Modell
M270H1-L01 Innolux 27.0 1920×1080
M270HGE-L20 Innolux 27.0 1920×1080
M270HGE-L30 Innolux 27.0 1920×1080
M270HHF-L10 Innolux 27.0 1920×1080
M270HTN01.0 AUO 27.0 1920×1080
M270HVN02.0 AUO 27.0 1920×1080
M270HW01 V0 AUO 27.0 1920×1080
M270HW01 V1 AUO 27.0 1920×1080
M270HW02 V1 AUO 27.0 1920×1080
M270HW02 V3 AUO 27.0 1920×1080
