| Part Number | SVA150XG04TB |
| Mark | SVA-NEC |
| Gréisst | 15.0 |
| Applikatioun | DMPC |
| Opléisung | 1024×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 250 |
| CR | 450:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | SVA-NEC |
| Panel Modell | SVA150XG04TB |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 15.0 inch |
| Resolutioun | 1024(RGB)×768 , XGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 304.128×228.096 mm |
| skizzéieren | 326.5×253.5×12 mm |
| Uewerfläch | |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 450:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), CIE193160% |
| Äntwert Zäit | 3/9 (Typ.)(Tr/Td) |
| Vue Wénkel | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 2 pcsCCFLWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 20 pins |
| Input Volt | 3.3V (Typ.) |
| rohs: | |
| Applikatioun | DMPC |
| CLAA150XP01Q V2 | CPT | 15.0 | 1024×768 |
| G150XG01 V2 | AUO | 15.0 | 1024×768 |
| LP150X05-A2C1 | LG Display | 15.0 | 1024×768 |
| LTM150XO-L01 | Samsung | 15.0 | 1024×768 |
| LTM15C423S | TOSHIBA | 15.0 | 1024×768 |
| LTM15C428S | TOSHIBA | 15.0 | 1024×768 |
| LTN150KT02-801 | Samsung | 15.0 | 1600×900 |
| M150X3-T05 | Innolux | 15.0 | 1024×768 |
| SVA150XG04TB | SVA-NEC | 15.0 | 1024×768 |
| SVA150XG10TB | SVA-NEC | 15.0 | 1024×768 |
