MT185GW01 V.0

MT185GW01 V.0
MT185GW01 V.0 thumb
Mark
Innolux
Gréisst
18.5
Applikatioun
DMPC
Opléisung
1366×768
Zesummesetzung
LCM
Hellegkeet
300
CR
1000:1
Faarwen
16.7M
Backlight
CCFL
Interface
LVDS
In Stock
7382
Spezifikatioune

Part Number MT185GW01 V.0
MarkInnolux
Gréisst18.5
ApplikatiounDMPC
Opléisung1366×768
ZesummesetzungLCM
Hellegkeet300
CR1000:1
Faarwen16.7M
GéigeliichtCCFL
InterfaceLVDS
Panel MarkINNOLUX
Panel ModellMT185GW01 V.0
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst18.5 inch
Resolutioun1366(RGB)×768 , WXGA
Display ModusTN, Normally White, Transmissive
aktiv Beräich409.8×230.4 mm
skizzéieren430.37×254.6×16.5 mm
UewerflächAntiglare (Haze 25%), Hard coating (3H)
Hellegkeet300 cd/m² (Typ.)
Kontrast Verhältnis1000:1 (Typ.)
weisen Faarwen16.7M (6-bit + Hi-FRC), CIE193172%
Äntwert Zäit1.5/3.5 (Typ.)(Tr/Td)
Vue Wénkel85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ2 pcsCCFLWithout Driver
Signal InterfaceLVDS (1 ch, 8-bit), 30 pins
Input Volt5.0V (Typ.)
ApplikatiounDMPC
Famill Modell
G185XW01 V2 AUO 18.5 1366×768
HT185WX1-300 BOE 18.5 1366×768
LM185TT4A PANDA 18.5 1366×768
LM185WH1-TLH1 LG Display 18.5 1366×768
M185XTN01.3 AUO 18.5 1366×768
M185XW01 V5 AUO 18.5 1366×768
MT185GW01 V.0 Innolux 18.5 1366×768
MT185GW01 V.4 Innolux 18.5 1366×768
MT185WHM-N10 BOE 18.5 1366×768
MT185WHM-N20 BOE 18.5 1366×768
