M270HW02 V1

M270HW02 V1
M270HW02 V1
M270HW02 V1
M270HW02 V1 thumb M270HW02 V1 thumb M270HW02 V1 thumb
Mark
AUO
Gréisst
27.0
Applikatioun
DMPC
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
300
CR
5000:1
Faarwen
16.7M
Backlight
WLED
Interface
LVDS
In Stock
493
Spezifikatioune

Part Number M270HW02 V1
MarkAUO
Gréisst27.0
ApplikatiounDMPC
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet300
CR5000:1
Faarwen16.7M
GéigeliichtWLED
InterfaceLVDS
Panel MarkAUO
Panel ModellM270HW02 V1
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst27.0 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusMVA, Normally Black, Transmissive
aktiv Beräich597.6×336.15 mm
skizzéieren630×368.2×12 mm
UewerflächAntiglare, Hard coating (3H)
Hellegkeet300 cd/m² (Typ.)
Kontrast Verhältnis5000:1 (Typ.)
weisen Faarwen16.7M (8-bit), CIE193172%
Äntwert Zäit7/5 (Typ.)(Tr/Td)
Vue Wénkel89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ18S4PWLEDWithout Driver
Signal InterfaceLVDS (2 ch, 8-bit), 30 pins
Input Volt5.0V (Typ.)
ApplikatiounDMPC
Famill Modell
M270HGE-L10 Innolux 27.0 1920×1080
M270HHF-L10 Innolux 27.0 1920×1080
M270HTN01.0 AUO 27.0 1920×1080
M270HVN02.0 AUO 27.0 1920×1080
M270HVN02.1 AUO 27.0 1920×1080
M270HW01 V0 AUO 27.0 1920×1080
M270HW01 V1 AUO 27.0 1920×1080
M270HW02 V0 AUO 27.0 1920×1080
M270HW02 V1 AUO 27.0 1920×1080
M270HW02 V3 AUO 27.0 1920×1080
