| Part Number | M270HGE-L30 |
| Mark | Innolux |
| Gréisst | 27.0 |
| Applikatioun | DMPC |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 1200:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | CHIMEI INNOLUX |
| Panel Modell | M270HGE-L30 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 27.0 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 597.888×336.312 mm |
| skizzéieren | 630×368.2×14.6 mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 1200:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Äntwert Zäit | 1.5/3.5 (Typ.)(Tr/Td) |
| Vue Wénkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 4 stringsWLEDWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | DMPC |
| M270H3-L01 | Innolux | 27.0 | 1920×1080 |
| M270HGE-L20 | Innolux | 27.0 | 1920×1080 |
| M270HGE-L30 | Innolux | 27.0 | 1920×1080 |
| M270HHF-L10 | Innolux | 27.0 | 1920×1080 |
| M270HVN02.0 | AUO | 27.0 | 1920×1080 |
| M270HVN02.1 | AUO | 27.0 | 1920×1080 |
| M270HW01 V0 | AUO | 27.0 | 1920×1080 |
| M270HW02 V0 | AUO | 27.0 | 1920×1080 |
| M270HW02 V1 | AUO | 27.0 | 1920×1080 |
| M270HW02 V3 | AUO | 27.0 | 1920×1080 |
| LC215EUE-TEA1 | LG Display | 21.5 | 1920×1080 |
| LM170E03-TLL1 | LG Display | 17.0 | 1280×1024 |
| LM215WF1-TLB1 | LG Display | 21.5 | 1920×1080 |
| LM250WF3-TLA1 | LG Display | 25.0 | 1920×1080 |
| LM340UW2-SSA1 | LG Display | 34 | 3440×1440 |
| LTM170EU-L21 | Samsung | 17.0 | 1280×1024 |
| M190MWW3 R0 | IVO | 19.0 | 1440×900 |
| M215XTN01.0 | AUO | 21.5 | 1366×768 |
| MT215DW01 V.1 | Innolux | 21.5 | 1920×1080 |
| NL10276AC24-05 | NLT | 12.1 | 1024×768 |
