| Part Number | LP101WX2-SLA1 |
| Mark | LG Display |
| Gréisst | 10.1 |
| Applikatioun | PAD |
| Opléisung | 1280×800 |
| Zesummesetzung | Assembly |
| Hellegkeet | 360 |
| CR | 500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | LG Display |
| Panel Modell | LP101WX2-SLA1 |
| Panel Typ | a-Si TFT-LCD , Assembly |
| Panel Gréisst | 10.1 inch |
| Resolutioun | 1280(RGB)×800 , WXGA |
| aktiv Beräich | 216.96×135.6 mm |
| skizzéieren | 257.2×175.4×5.9 mm |
| Uewerfläch | Anti Fingerprint |
| Hellegkeet | 360 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Min.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signal Interface | LVDS (1 ch, 8-bit), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | PAD |
| LP101WH1-TLA1 | LG Display | 10.1 | 1366×768 |
| LP101WH1-TLB5 | LG Display | 10.1 | 1366×768 |
| LP101WH2-TLA2 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLAB | LG Display | 10.1 | 1366×768 |
| LP101WS1-TLB2 | LG Display | 10.1 | 1024×576 |
| LP101WSA-TLA1 | LG Display | 10.1 | 1024×600 |
| LP101WSA-TLB1 | LG Display | 10.1 | 1024×600 |
| LP101WX1-SLB1 | LG Display | 10.1 | 1280×800 |
| LP101WX1-SLP2 | LG Display | 10.1 | 1280×800 |
| LP101WX2-SLA1 | LG Display | 10.1 | 1280×800 |
| B116XAN03.1 HW1A | AUO | 11.6 | 1366×768 |
| CLAA080WQ02 XN | CPT | 8.0 | 800×1280 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| HV101HD1-1E2 | HYDIS | 10.1 | 1366×768 |
| LD080UX1-SMA2 | LG Display | 8.0 | 1200×1600 |
| LP097QX1-SPC1 | LG Display | 9.7 | 2048×1536 |
| LSL080AL02-002 | Samsung | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.A1 | Innolux | 8.0 | 800×1280 |
| TV097X0M-NS0 | BOE | 9.7 | 768×1024 |
| VVX10F008B00 | Panasonic | 10.1 | 1920×1200 |
