| Part Number | LSL080AL02-002 |
| Mark | Samsung |
| Gréisst | 8.0 |
| Applikatioun | PAD |
| Opléisung | 800×1280 |
| Zesummesetzung | CELL |
| Hellegkeet | 0 |
| CR | 900:1 |
| Faarwen | 16.7M |
| Géigeliicht | No B/L |
| Interface | MIPI |
| Panel Mark | SAMSUNG |
| Panel Modell | LSL080AL02-002 |
| Panel Typ | a-Si TFT-LCD , CELL |
| Panel Gréisst | 8.0 inch |
| Resolutioun | 800(RGB)×1280 , WXGA |
| Display Modus | PLS, Normally Black, Transmissive |
| aktiv Beräich | 107.64×172.224 mm |
| skizzéieren | 112.64×181.824×0.69 mm |
| Uewerfläch | Glare (Haze 0%), Hard coating |
| Glas Déift | 0.20+0.20 mm |
| transmissivitéit | 6.6% (Typ.)(with Polarizer) |
| Kontrast Verhältnis | 900:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 16 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signal Interface | MIPI (4 data lanes), 34 pins |
| Input Volt | 1.8/3.3V (Typ.)(DVDD/PVDD) |
| Applikatioun | PAD |
