| Part Number | LH550WF4-SD01 |
| Mark | LG Display |
| Gréisst | 5.5 |
| Applikatioun | MPH |
| Opléisung | 1080×1920 |
| Zesummesetzung | Assembly |
| Hellegkeet | 550 |
| CR | 1600:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Panel Mark | LG Display |
| Panel Modell | LH550WF4-SD01 |
| Panel Typ | LTPS TFT-LCD , Assembly |
| Panel Gréisst | 5.5 inch |
| Resolutioun | 1080(RGB)×1920 , FHD |
| aktiv Beräich | 68.364×121.536 mm |
| skizzéieren | 75.27×155.55×2.35 mm |
| Uewerfläch | |
| Hellegkeet | 550 cd/m² (Typ.) |
| Kontrast Verhältnis | 1600:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193170% |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signal Interface | MIPI (4 data lanes), 36 pins |
| Input Volt | 1.8//5.7/-5.7V (Typ.)(DVDD/AVDDH/AVDDN) |
| Applikatioun | MPH |
