| Part Number | LH550WF2-SD03 |
| Mark | LG Display |
| Gréisst | 5.5 |
| Applikatioun | MPH |
| Opléisung | 1080×1920 |
| Zesummesetzung | LCM |
| Hellegkeet | 460 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Panel Mark | LG Display |
| Panel Modell | LH550WF2-SD03 |
| Panel Typ | LTPS TFT-LCD , LCM |
| Panel Gréisst | 5.5 inch |
| Resolutioun | 1080(RGB)×1920 , FHD |
| Display Modus | AH3-IPS, Normally Black, Transmissive |
| aktiv Beräich | 68.04×120.96 mm |
| skizzéieren | 70.94×128.01×1.55 mm |
| Uewerfläch | |
| Hellegkeet | 460 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193170% |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 6S2PWLEDWithout Driver |
| Signal Interface | MIPI (4 data lanes), 50 pins |
| Input Volt | 1.8/5.0/-5.0V (Typ.)(VDD/VAN/VPG) |
| Applikatioun | MPH |
