| Part Number | LMS241GF31 |
| Mark | Samsung |
| Gréisst | 2.4 |
| Applikatioun | MPH |
| Opléisung | 240×320 |
| Zesummesetzung | LCM |
| Hellegkeet | 230 |
| CR | 500:1 |
| Faarwen | 65K |
| Géigeliicht | WLED |
| Interface | CPU |
| Panel Mark | SAMSUNG |
| Panel Modell | LMS241GF31 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 2.4 inch |
| Resolutioun | 240(RGB)×320 , QVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 36.72×48.96 mm |
| skizzéieren | 42.72×60.26×3.92 mm |
| Uewerfläch | Hard coating (2H) |
| Hellegkeet | 230 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 65K , CIE193155% |
| Äntwert Zäit | 35 (Max.)(Tr+Td) |
| Vue Wénkel | 45/45/45/45 (Typ.)(CR≥10)(L/R/U/D) |
| Lampe Typ | 1S4PWLEDWithout Driver |
| Signal Interface | CPU, 37 pins |
| Input Volt | 2.8/2.8V (Typ.)(VCC/VCI) |
| Applikatioun | MPH |
