| Part Number | ES050YMM-A00 |
| Mark | BOE |
| Gréisst | 5.0 |
| Applikatioun | Round Display Instru |
| Opléisung | 1080×1080 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1300:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED , No Driver |
| Interface | |
| Fabrikant beschwéiert | BOE |
| Modell Numm | ES050YMM-A00 |
| Écran Gréisst | 5.0 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 1080(RGB)×1080 215PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 127.008 × 127.008 (H×V) |
| Kontur (mm) | 143 × 140 × 4.45 (H×V×D) |
| luminance | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 1300 : 1 (Typ.) (TM) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| Äntwert | 40 (Max.)(Tr+Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | ADS, Normally Black, Transmissive |
| Faarfdéift | 16.7M 80% NTSC |
| mass | - |
| benotzt fir | Round Display Instruments & Meters Home Appliance |
| Erfrëschungsrate | 60Hz |
| touchscreen | PCAP |
| Storage Temp.: -30 ~ 75 °C Operating Temp.: -20 ~ 60 °C |
