| Part Number | CLAA048LA0ACT |
| Mark | CPT |
| Gréisst | 4.8 |
| Applikatioun | |
| Opléisung | 800×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 280 |
| CR | 400:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | CPT |
| Panel Modell | CLAA048LA0ACT |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 4.8 inch |
| Resolutioun | 800(RGB)×480 , WVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 103.8×62.28 mm |
| skizzéieren | 114.65×74.7 mm |
| Uewerfläch | Glare (Haze 0%), Hard coating (3H) |
| Hellegkeet | 280 cd/m² (Typ.) |
| Kontrast Verhältnis | 400:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193148% |
| Äntwert Zäit | 20 (Typ.)(Tr+Td) |
| Vue Wénkel | 65/65/40/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 6-bit), 30 pins |
| Input Volt | 3.3V (Typ.) |
