| Part Number | LH480HX1-SD01 |
| Mark | LG Display |
| Gréisst | 4.8 |
| Applikatioun | MPH |
| Opléisung | 480×1024 |
| Zesummesetzung | LCM |
| Hellegkeet | 500 |
| CR | 700:1 |
| Faarwen | 16.2M |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | LG Display |
| Panel Modell | LH480HX1-SD01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 4.8 inch |
| Resolutioun | 480(RGB)×1024 |
| Display Modus | IPS, Normally Black, Transmissive |
| aktiv Beräich | 51.84×110.592 mm |
| skizzéieren | 57.64×121.45 mm |
| Uewerfläch | |
| Hellegkeet | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 700:1 (Typ.) |
| weisen Faarwen | 16.2M (6-bit + Dithering), CIE193168% |
| Äntwert Zäit | 35 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 5S2PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| Input Volt | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| Applikatioun | MPH |
