| Part Number | TD025THED2 |
| Mark | TPO |
| Gréisst | 2.5 |
| Applikatioun | MPH |
| Opléisung | 320×240 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 350:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | TPO |
| Panel Modell | TD025THED2 |
| Panel Typ | LTPS TFT-LCD , LCM |
| Panel Gréisst | 2.5 inch |
| Resolutioun | 320(RGB)×240 , QVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 49.92×37.44 mm |
| skizzéieren | 56.4×49.12×2.5 mm |
| Uewerfläch | |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 350:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193170% |
| Äntwert Zäit | 20 (Typ.)(Tr+Td) |
| Vue Wénkel | 55/55/55/55 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit) + SPI, 39 pins |
| Input Volt | 1.8/2.8V (Typ.)(VDDI/VDD) |
| Applikatioun | MPH |
