| Part Number | LTP280QV-E01 |
| Mark | Samsung |
| Gréisst | 2.8 |
| Applikatioun | MPH |
| Opléisung | 240×320 |
| Zesummesetzung | LCM |
| Hellegkeet | 110 |
| CR | 150:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | SAMSUNG |
| Panel Modell | LTP280QV-E01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 2.8 inch |
| Resolutioun | 240(RGB)×320 , QVGA |
| Display Modus | TN, Normally White, Transflective |
| aktiv Beräich | 43.2×57.6 mm |
| skizzéieren | 52.9×71.7×4.75 mm |
| Uewerfläch | Hard coating (3H) |
| Hellegkeet | 110 cd/m² (Typ.) |
| Kontrast Verhältnis | 150:1 (Typ.)(Transmissive)6:1 (Typ.)(Reflective) |
| weisen Faarwen | 262K (6-bit), CIE193130% |
| Äntwert Zäit | 35 (Typ.)(Tr+Td) |
| Vue Wénkel | 50/40/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| Lampe Typ | 6S1PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 61 pins |
| Input Volt | 3.3/5.0/15/-10V (Typ.)(DVDD/AVDD/VON/VOFF) |
| Applikatioun | MPH |
