| Part Number | TM028HDH21 |
| Mark | Tianma |
| Gréisst | 2.8 |
| Applikatioun | MPH |
| Opléisung | 240×320 |
| Zesummesetzung | LCM |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | CPU |
| Panel Mark | TIANMA |
| Panel Modell | TM028HDH21 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 2.8 inch |
| Resolutioun | 240(RGB)×320 , QVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 43.2×57.6 mm |
| Uewerfläch | Clear |
| Hellegkeet | |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193150% |
| Äntwert Zäit | 20 (Typ.)(Tr+Td) |
| Vue Wénkel | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDWithout Driver |
| Signal Interface | 8/16-bit 8080 parallel, 37 pins |
| Input Volt | 2.8/2.8V (Typ.)(IDDIO/VCC) |
| Applikatioun | MPH |
