B101UAT02.1

B101UAT02.1
B101UAT02.1
B101UAT02.1 thumb B101UAT02.1 thumb
Mark
AUO
Gréisst
10.1
Applikatioun
PAD
Opléisung
1920×1200
Zesummesetzung
LCM
Hellegkeet
CR
800:1
Faarwen
16.7M
Backlight
WLED
Interface
LVDS
In Stock
7404
Spezifikatioune

Part Number B101UAT02.1
MarkAUO
Gréisst10.1
ApplikatiounPAD
Opléisung1920×1200
ZesummesetzungLCM
Hellegkeet
CR800:1
Faarwen16.7M
GéigeliichtWLED
InterfaceLVDS
Panel MarkAUO
Panel ModellB101UAT02.1
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst10.1 inch
Resolutioun1920(RGB)×1200 , WUXGA
Display ModusAHVA, Normally Black, Transmissive
aktiv Beräich216.81×135.5 mm
Uewerfläch
Hellegkeet
Kontrast Verhältnis800:1 (Typ.)
weisen Faarwen16.7M (8-bit)
Äntwert Zäit13/12 (Typ.)(Tr/Td)
Vue Wénkel89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe TypWLED
Signal InterfaceLVDS (2 ch, 8-bit)
ApplikatiounPAD
Famill Modell
B101UAN01.1 AUO 10.1 1920×1200
B101UAN01.7 HW0A AUO 10.1 1920×1200
B101UAN01.7 HW1A AUO 10.1 1920×1200
B101UAN01.7 HW2A AUO 10.1 1920×1200
B101UAN01.9 AUO 10.1 1920×1200
B101UAN01.E AUO 10.1 1920×1200
B101UAN02.1 AUO 10.1 1920×1200
B101UAN07.0 AUO 10.1 1200×1920
B101UAN07.2 AUO 10.1 1200×1920
B101UAT02.1 AUO 10.1 1920×1200
