| Part Number | AM-1024600Y3TZQW-A0H |
| Mark | AMPIRE |
| Gréisst | 9.0 |
| Applikatioun | Industrial |
| Opléisung | 1024×600 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | AMPIRE |
| Panel Modell | AM-1024600Y3TZQW-A0H |
| Panel Gréisst | 9.0" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1024(RGB)×600, WSVGA, 132PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 196.6(W)×114.1(H) mm |
| bezel Ouverture | 200(W)×117.55(H) mm |
| Kontur Gréisst | 211.1(W)×126.5(H) ×11(D) mm |
| Uewerfläch | - |
| Hellegkeet | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Display Modus | Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 18/17 (Typ.)(Tr/Td) |
| weisen Faarwen | 16.7M |
| Lampe Typ | WLED , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | TBD |
| Applikatioun | Industrial |
| Signal Interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
