| Part Number | AM-1024600KTMQW-04H |
| Mark | AMPIRE |
| Gréisst | 7.0 |
| Applikatioun | CNS |
| Opléisung | 1024×600 |
| Zesummesetzung | LCM |
| Hellegkeet | 1000 |
| CR | 700:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | AMPIRE |
| Panel Modell | AM-1024600KTMQW-04H |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.0 inch |
| Resolutioun | 1024(RGB)×600 , WSVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 153.6×90 mm |
| skizzéieren | 165.5×104.44×5.3 mm |
| Uewerfläch | Glare (Haze 0%), Hard coating |
| Hellegkeet | 1000 cd/m² (Typ.) |
| Kontrast Verhältnis | 700:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 10/15 (Typ.)(Tr/Td) |
| Vue Wénkel | 75/75/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 8S3PWLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 39 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | CNS |
