| Part Number | HJ070IA-02F |
| Mark | Innolux |
| Gréisst | 7.0 |
| Applikatioun | UMPC |
| Opléisung | 1280×800 |
| Zesummesetzung | LCM |
| Hellegkeet | 350 |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | CHIMEI INNOLUX |
| Panel Modell | HJ070IA-02F |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.0 inch |
| Resolutioun | 1280(RGB)×800 , WXGA |
| Display Modus | IPS, Normally Black, Transmissive |
| aktiv Beräich | 149.76×93.6 mm |
| skizzéieren | 161.2×107.2×4.5 mm |
| Uewerfläch | Hard coating |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193150% |
| Äntwert Zäit | 15/20 (Typ.)(Tr/Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 40 pins |
| Input Volt | 3.3/9.74/22.7/-8V (Typ.)(VDD/AVDD/VGH/VGL) |
| Applikatioun | UMPC |
| CLAA070NC0DCW | CPT | 7.0 | 1024×600 |
| CLAA070NP01 | CPT | 7.0 | 1024×600 |
| HJ070IA-02F | Innolux | 7.0 | 1280×800 |
| HSD070PWW1-C00 | HannStar | 7.0 | 1280×800 |
| LD070WS2-SL01 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL04 | LG Display | 7.0 | 1024×600 |
| LQ050W1LA0A | SHARP | 5.0 | 1024×600 |
| LT080EE04000 | TOSHIBA | 8.0 | 1600×768 |
| LTL070AL01-L01 | Samsung | 7.0 | 1280×800 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
