| Part Number | TM090JDH01 |
| Mark | Tianma |
| Gréisst | 9.0 |
| Applikatioun | PAD |
| Opléisung | 1280×800 |
| Zesummesetzung | LCM |
| Hellegkeet | 250 |
| CR | 700:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | TIANMA |
| Panel Modell | TM090JDH01 1 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 9.0 inch |
| Resolutioun | 1280(RGB)×800 , WXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 193.92×121.2 mm |
| skizzéieren | 206.76×135.06×4.8 mm |
| Uewerfläch | |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 700:1 (Typ.) |
| weisen Faarwen | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193170% |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 3S12PWLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 6/8-bit), 51 pins |
| Input Volt | 3.3/11/20/-6.8V (Typ.)(VCC/AVDD/VGH/VGL) |
| Applikatioun | PAD |
