| Part Number | UG-2864ASYCG01 |
| Mark | WiseChip |
| Gréisst | 1.54 |
| Applikatioun | IA |
| Opléisung | 128×64 |
| Zesummesetzung | OLED |
| Hellegkeet | 150 |
| CR | 10000:1 |
| Faarwen | Mono(Yellow) |
| Géigeliicht | self |
| Interface | CPU/SPI/I²C |
| Panel Mark | WiseChip |
| Panel Modell | UG-2864ASYCG01 |
| Panel Typ | PM-OLED , OLED |
| Panel Gréisst | 1.54 inch |
| Resolutioun | 128×64 |
| aktiv Beräich | 35.056×17.52 mm |
| skizzéieren | 45.24×29.14×2.1 mm |
| Uewerfläch | |
| Hellegkeet | 150 cd/m² (Typ.) |
| Kontrast Verhältnis | 10000 : 1 (Typ.) |
| weisen Faarwen | Mono(Yellow) (1-bit) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Chauffeur ic | COG Built-in SSD1305 |
| Signal Interface | 8-bit 6800/8080 parallel, 4-wire SPI, I²C, 24 pins |
| Input Volt | 2.8/12.5V (Typ.)(VDD/VCC) |
| rohs: | |
| Applikatioun | IA |
