| Part Number | TX16D18VM2CAB |
| Mark | KOE |
| Gréisst | 6.2 |
| Applikatioun | IA |
| Opléisung | 800×300 |
| Zesummesetzung | LCM |
| Hellegkeet | 350 |
| CR | 200:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | HITACHI |
| Panel Modell | TX16D18VM2CAB |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 6.2 inch |
| Resolutioun | 800(RGB)×300 , HSVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 148.8×53.76 mm |
| skizzéieren | 173×70 mm |
| Uewerfläch | |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 200:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193160% |
| Äntwert Zäit | 45 (Typ.)(Tr+Td) |
| Vue Wénkel | 70/70/50/80 (Typ.)(CR≥5)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 3S7PWLEDWithout Driver |
| Signal Interface | CMOS (1 ch, 6-bit), 40 pins |
| Input Volt | 3.3V (Typ.)(VDD) |
| Applikatioun | IA |
