| Part Number | G104XVN01.0 |
| Mark | AUO |
| Gréisst | 10.4 |
| Applikatioun | IA |
| Opléisung | 1024×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 470 |
| CR | 3000:1 |
| Faarwen | 262K/16.2M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | G104XVN01.0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 10.4 inch |
| Resolutioun | 1024(RGB)×768 , XGA |
| Display Modus | PSA, Normally Black, Transmissive |
| aktiv Beräich | 210.4×157.8 mm |
| skizzéieren | 238.6×175.8×7 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 470 cd/m² (Typ.) |
| Kontrast Verhältnis | 3000:1 (Typ.) |
| weisen Faarwen | 262K/16.2M (6-bit / 6-bit + FRC), CIE193160% |
| Äntwert Zäit | 20/10 (Typ.)(Tr/Td) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 2 stringsWLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 6/8-bit), 30 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | IA |
