LP104V2-W

LP104V2-W
LP104V2-W
LP104V2-W
LP104V2-W thumb LP104V2-W thumb LP104V2-W thumb
Mark
LG Display
Gréisst
10.4
Applikatioun
NBPC
Opléisung
640×480
Zesummesetzung
LCM
Hellegkeet
200
CR
150:1
Faarwen
262K
Backlight
CCFL
Interface
TTL
In Stock
460
Spezifikatioune

Part Number LP104V2-W
MarkLG Display
Gréisst10.4
ApplikatiounNBPC
Opléisung640×480
ZesummesetzungLCM
Hellegkeet200
CR150:1
Faarwen262K
GéigeliichtCCFL
InterfaceTTL
Panel MarkLG.Philips LCD
Panel ModellLP104V2-W
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst10.4 inch
Resolutioun640(RGB)×480 , VGA
Display ModusTN, Normally White, Transmissive
aktiv Beräich211.2×158.4 mm
skizzéieren246.5×179.4 mm
UewerflächAntiglare, Hard coating (3H)
Hellegkeet200 cd/m² (Typ.)
Kontrast Verhältnis150:1 (Typ.)
weisen Faarwen262K (6-bit)
Äntwert Zäit30/50 (Typ.)(Tr/Td)
Vue Wénkel70/70/45/50 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ1 pcsCCFLWithout Driver
Signal InterfaceTTL (1 ch, 6-bit), 31 pins
Input Volt3.3V (Typ.)(VDD)
ApplikatiounNBPC
