| Part Number | TX20D33VM2BAC |
| Mark | KOE |
| Gréisst | 8.0 |
| Applikatioun | Industrial |
| Opléisung | 800×480 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 600:1 |
| Faarwen | 262K |
| Géigeliicht | WLED , 50K hours , No Driver |
| Interface | CMOS |
| Fabrikant beschwéiert | KOE |
| Écran Gréisst | 8.0 inch |
| Pixel Zuel | 800(RGB)×480 (WVGA) 116PPI |
| aktiv Beräich (mm) | 174 × 104.4 (H×V) |
| Bezel Beräich (mm) | 187.0 × 108.4 (H×V) |
| luminance | - |
| Vue Wénkel | 80/80/60/80 (Typ.)(CR≥10) |
| gutt Vue op | 6 o'clock |
| Faarfdéift | 262K |
| mass | 160g |
| Erfrëschungsrate | 60Hz |
| Signal Typ | CMOS (1 ch, 6-bit) , 40 pins Connector |
| Spannungsversuergung | 3.3V (Typ.) |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| Modell Numm | TX20D33VM2BAC |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 189 × 120 × 8 (H×V×D) |
| Behandlung | - |
| Kontrast Verhältnis | 600 : 1 (Typ.) (TM) |
| Äntwert | 20 (Typ.)(Tr+Td) ms |
| Aarbecht Modus | TN, Normally White, Transmissive |
| benotzt fir | Industrial |
| touchscreen | Without |
