| Part Number | TX20D207VM0AAA |
| Mark | KOE |
| Gréisst | 8.0 |
| Applikatioun | Industrial Automotiv |
| Opléisung | 1280×768 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1400:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | KOE |
| Panel Modell | TX20D207VM0AAA |
| Panel Gréisst | 8.0" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1280(RGB)×768, WXGA, 186PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 173.952(W)×104.371(H) mm |
| bezel Ouverture | 177.0(W)×107.4(H) mm |
| Kontur Gréisst | 189.5(W)×119.4(H) ×12.1(D) mm |
| Uewerfläch | - |
| Hellegkeet | 1200 cd/m² (Typ.) |
| Kontrast Verhältnis | 1400:1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Display Modus | IPS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 19 (Typ.)(Tr+Td) |
| weisen Faarwen | 16.7M 70% NTSC |
| Lampe Typ | WLED , 70K hours , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | 254g (Typ.) |
| Applikatioun | Industrial Automotive Display |
| Signal Interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| BP080WX1-100 | BOE | 8.0 | 1280×800 |
| L5F30614T64 | SANYO | 8.0 | 800×480 |
| LA080WV3-SD01 | LG Display | 8.0 | 800×480 |
| LQ080V3DG01 | SHARP | 8.0 | 640×480 |
| LQ080Y5DW03 | SHARP | 8.0 | 800×480 |
| N080ICE-GB0 Rev.A1 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.C1 | Innolux | 8.0 | 800×1280 |
| N080JCE-G41 | Innolux | 8.0 | 1200×1920 |
| TM080VDSP01 | Tianma | 8.0 | 1200×1920 |
| TM080XPH01 | Tianma | 8.0 | 1280×768 |
