| Part Number | TM080VDSP01 |
| Mark | Tianma |
| Gréisst | 8.0 |
| Applikatioun | PAD |
| Opléisung | 1200×1920 |
| Zesummesetzung | LCM |
| Hellegkeet | 390 |
| CR | 900:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Panel Mark | TIANMA |
| Panel Modell | TM080VDSP01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 8.0 inch |
| Resolutioun | 1200(RGB)×1920 , WUXGA |
| Display Modus | SFT, Normally Black, Transmissive |
| aktiv Beräich | 107.64×172.224 mm |
| skizzéieren | 114.6×184.1×2.3 mm |
| Uewerfläch | |
| Hellegkeet | 390 cd/m² (Typ.) |
| Kontrast Verhältnis | 900:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193160% |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 7S3PWLEDWithout Driver |
| Signal Interface | MIPI (4 data lanes), 31 pins |
| Input Volt | 3.3/10.0/18.0/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| Applikatioun | PAD |
